Number of spindles | 256 |
Size of yarn winding bobbin | L240-320×φ42×φ110 |
Size of winding bobbin | φ160×φ89×L165×L173 |
Spindle gauge | 225mm |
Max.spindle speed | 15000r/min |
Normal spindle speed | 8000-14000r/min |
Twist range | 350-3989 T/M ( Need to be selected ) |
Twist direction | S / Z |
Form of spindle driving | Belt circulating drive |
Spindle fixture | Magnetic fixture |
Start mode | Start-delta slowatart |
Tensioner | Ball tension device |
Take-up tension | Adjust the yarn in roller angle |
Power motor | 7.5KW×2 |
Overall size | 16410×750×1895mm |
